Non woven disposable face mask making machine
| Size | 6000mm(L)3500mm(W)1900mm(H) |
| Voltage | 220V |
| Weight | 1.5T |
| Power | 8KW |
| Production capacity | 90-120pcs/min |
| Certification | ISO SGS TUV |
1. Introduction to equipment
The automatic mask body machine is mainly used for the automatic forming of flat plane masks. After the entire roll of fabric is
unrolled, it is driven by rollers.Thefabric is automatically unfolded by automatic hemming, hemming, and the nose bridge. In
both sides, the sealing is achieved by ultrasonic welding on both sides. After the ultrasonic side sealing, cuttingisperformed by
a cutter, and thewhole process is automatically controlled. Only one person is required to operate this machine. The scientific
and reasonable mechanicaltransmission configuration makes this machine extremely efficient. The special welding wheel and
cutter wheel design have good abrasion resistance and greatly increase the service life of the product.
2. Equipment installation and configuration requirements
Equipment size: 3500mm (L) x 1100mm(W) x 2100mm (H);
Equipment weight:1600KG
Working voltage: AC220V,50 / 60HZ, rated power: 4KW
Compressed air: 0.5-0.7Mpa
Operating environment: temperature 10-35 ℃, humidity 5-35% HR, no flammability, corrosive gas, no dust (cleanness noless
than 100,000)
3. Equipment characteristics
The machine adopts aluminum alloy structure, small size, stable operation and low scrap rate;
Equippedwith photoelectricdetection and automatic counting, which can control the production speed and high output;
It can produce 100 pieces per minute, and can produce (3-6 layers) multilayer masks.
